The laser jewelry welding machine adopts the electronic generation laser method for welding, which uses the fine high temperature of the laser to quickly melt and weld. Laser jewelry welding machine can weld dazzling jewelry, because there is no gap, exquisiteness is reflected in the characteristics of laser welding machine, so that women with jewelry.Sex is more confident and dazzling. Laser spot welders, also called jewelry spot welders, can weld the same or different materials together. In the jewelry industry, the traditional processing technology has a high growth rate, a long cycle, and a poor customer experience. Laser processing technology has relatively significant advantages. In recent years, laser jewelry welding machine processing technology has become more and more widely used in jewelry worldwide.
| Name | Laser Jewelry Welding Machine, Laser Spot Welding Machine | ||
| Model | RA-VR100 | RA-VR150 | RA-VR200 |
| Laser Power | 100W | 150W | 200W |
| Laser Wavelength 1064mm | 1064mm | 1064mm | 1064mm |
| Volage Regulating(Customized) | 100-400VDC | 100-400VDC | 100-400VDC |
| Pulse width | 0.1-20ms | 0.1-20ms | 0.1-20ms |
| Beam Diameter | 0.2-2mm | 0.2-2mm | 0.2-2mm |
| Laser Welding Working Distance | 100-300mm | 100-300mm | 100-300mm |
| Aiming and Positioning | Microscope +CCD (Combined) | Microscope +CCD (Combined) | Microscope +CCD (combined) |
| Power | ≤5KW | ≤6KW | ≤6KW |
| Machine Dimension | 54*29*29cm | 56*29*29cm | 58.8*35*29cm |
| Machine Net weight | 28KG | 34KG | 39KG |
| Package size | 64*52*50cm | 64*52*50cm | 76.5*46.2*57cm |
| Gross weight | 40.5kg | 48KG | 58KG |
| Language | Chinese, English, Japanese, Spanish, Korean, Arabic, Portuguese, Russian, Turkish, Italian(Customized) | ||
| Application | Application Welding and repairing all kinds of metal jewelry | ||
Laser jewelry welding machine the characteristics of high welding strength and speed, and low rejection rate, and is widely used in jewelry manufacturing. Compared with traditional welding technology, it has the following advantages:
Fast speed, high strength, small deformation, no need for correction and cleaning after welding;
Laser jewelry welding machine is suitable for welding precision workpieces, which can ensure the processing quality;
The assembly precision is high, which is helpful for the development of new technology;
Good consistency and stability;
Laser jewelry welding machine can simplify the repair work of the workpiece;
Environmental protection and pollution-free;
Save processing metal materials.
Laser jewelry welding machine uses high-energy laser pulses to locally heat the material in a small area. The energy of the laser radiation diffuses into the material through heat conduction, and the material is melted to form a specific molten pool.
Laser jewelry welding machine is widely used for precision welding of various small parts, such as jewelry, electronics, communications, hardware, watches, military and many other industries and fields.
1.The Laser jewelry welding machine has a two warranty, except for the parts that can be touched by the ink and our online technical support and software for the machines are always free;
2.Each customer will have one to one after-sales technical personnel service, including installation, use and later machine use in any problem can be at any time to serve you;
3.The manufacturing and testing of products have quality records and testing data;
4. For product performance testing, users are sincerely invited to check the whole process and performance of the product in person, and then pack and ship the product after it is confirmed to be qualified;
5.In order to ensure the high reliability and advancement of the product, the selection of the system is made of domestic or international high-quality brand-name products.
6. Under the same competitive conditions, on the basis of not reducing product technical performance and changing product components, we will sincerely provide you with the most favorable price.
Q1: Are you a factory or a trading company ?
A1: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.
Q2: How was the machine guarantee?
A2: We offer you 24 months guarantee.
Q3: How can I use the machine, if I'm a new buyer?
A3: We will deliver English manual and video with the machine to you. If you still need our help, please contact us.
Q4: How do you control your quality?
A4: We'll test the machine before the shipment, and let it go through every corner to check the accuracy. Machines can not be dispatched until finished machine pass all essential complicated test after running at least two days without stopping to ensure quality.
Q5: How can I know your machine is designed for my product?
A5: You can send us samples of your product and we test it on machine.
